Latest from the Installation Gallery

Lighting Installation At Mashriq Occasions in Bradford

Mashriq Occasions, Bradford

Mashriq Occasions, a wedding venue located on the outskirts of Bradford were looking for a lighting installation to enhance their venue enabling them to offer couples a wide choice of lighting styles to suit their individual wedding theme.

One of the most important aspects that Mashriq management wanted was for any lighting to be as hidden as possible without ruining the overall lighting effect or spoil the look of the venue. To this end Audioserv engineered 8 custom made boxes that were recessed into the roof hiding the bottom half of the lighting fixtures whilst securing the fixtures tightly in place.

For the lighting itself Audioserv picked the American DJ Focus Spot 5Z moving head for it's intense light output from a small body, superb colours, motorized focus and 6 facet prism with a frost effect generating a wash effect.

All this is controlled from a PC hidden out of sight running Avolites Lighting Software so the venue can change the look of the venue at the click of a button.


Void Acoustics are renowned for their innovative sonic and aesthetic design, which is why they were chosen for the opulent penthouse in the well known Leeds Bar, Fibre.

Audioserv installed Void’s red Airten V2 10″ speakers and the Reflex-loaded dual 12″ low frequency loudspeakers in the main bar area and the indigo 6 pro speakers for the quieter areas, all in Void’s signature red.

We designed and fabricated bespoke custom built brackets to suit the architecture of the building. Fibre’s penthouse VIP lounge, really has everything: the luxurious fixtures and fittings and an audio system that looks and sounds amazing.

"“Pete and his team at Audioserv have looked after our venues sound system for many years. From full Funktion One and Void installs to festival sound hire, servicing and repairs, these guys have always proved to be reliable and knowledgeable in their field. Highly recommend for anyone looking for a one stop shop when it comes to all aspects of professional sound systems.” - PJ Gardner, Bar Fibre.

Void Sound System Installation at Fibre in Leeds, West Yorkshire
Void Airten V2 10" Speaker Installation
Void Red Airten V2 10" Speaker System Install at Fibre in Leeds
Void Reflex Loaded Dual 12" Low Frequency Loudspeaker installation
Hawkhill Tavern - Audio Installation


Hawkhill Tavern Guiseley needed an audio system that was both discrete and sounded great. It has multiple areas which all needed consistent coverage.

We installed AUDAC Ateo 6 speakers across the venue, using multiple amplifier channels to allow for both different levels and correct time alignment to give seamless venue coverage.

The Ateo 6 speakers are accompanied by Audac Baso series subs. There are two Baso-12 inch subs downstairs along with one Baso-15 inch sub and two Baso 12 subs upstairs. The system is run by a Symetrix Jupiter 8 processor which provides the time alignment, EQ, crossover filters, and routing. It also provides control, which is done over IP to ipads behind the bar.

Hawkhill Tavern Guiesley - PA System Installation
Hawkhill Tavern Guiesley - PA Sound System Installation

The speakers are powered by three Audac SMQ series four channel amplifiers, which provide ample power to the venue. There are two Audac Cira ceiling mounted speakers in the ladies and gents to complete the experience.

“We use Audioserv on all our projects including the Roxy Ball Room concepts which we have recently opened up in Leeds, Liverpool, Manchester and Nottingham. Audioserv have supplied and installed the sound systems without any problems. I would highly recommend them!” - Ben Jones, Roxy Leisure.

Hawkhill Tavern - Speaker System Installation

Club Mission, Leeds

Funktion-One system installation in the main arena for Club Mission in Leeds.

In each stack, two Evo 7EH mid high elements are given effortless low mids by two F215MK2 on top of two F124 subs. A pair of F1201 are being used for DJ monitors. All this run from Linea Research 44C series amplifiers. DJ mixers in the venue depend on the artists’ requests, but the venue have a standard stock of Allen & Heath Xone 96 and Xone 92, plus Pioneer DJM900NX2 plus CDJ2000NX2 and CDJ2000NXS.

This system install featured in the industry magasine mondo dr, see the full article here: Mondo dr Article.

Funktion One installation at Club Mission in Leeds
Club Mission Leeds - Audio Installation
Club Mission Leeds
Club Mission Leeds - Audioserv providing Funktion One Sound System Installation
